Lite Version 4K30Hz HDBaseT HDMI Extender
Description
Technical Parameters
The MSLFORCE OEM New HBDT-HD-70TX/RX-MTK is an HDBaseT technology Extender, it supports no compression, no losses, no latency HDMI signal transmission. It can can work with other HDBaseT equipment, such as Sony HDBaseT projector. All the signals are transmitted by one single CAT5E/ CAT6/ CAT7 cable, for 1080P it can transmit to a distance of 70m(230ft), for 4K60Hz(4:2:0) it can up to 35m(115ft). Compatible with all the HDTV resolutions, HDCP2.2 protocol. It also supports bi-directional RS232 and IR transmission and realize the long distance control. Supports power over cable, users only need to power one side; It can be popularly used in media conferencing room, school, government, cinema and so on applications.
Key Features and Benefits
- Transmit highest quality audio and video, for 1080p can up to 220 feet and 4K60(4:2:0) can up to 115feet with Cat6/6a/7 cable
- Supports FULL HD, UHD, 3D, 4K60Hz
- HDCP2.2, HDMI2.0
- Bidirectional IR/Serial control signal transmission
- Power over Cable (POC) locally powered over Cat5e/6 cable at either end
- Supports 7.1 DTS Master HD, Dolby True HD,
- LED indicators, EDID pass-though
- Supports CEC control
Specifications
| Model No: | HBDT-HD-70TX-MTK | HBDT-HD-70RX-MTK | |
| Input : |
1x HDMI,1x RS232, 1x IR-TX,1x IR-RX |
1x HDBaseT |
|
| Output: |
1x HDBaseT |
1x HDMI,1x RS232, 1x IR-TX,1x IR-RX | |
| Protocol: |
Support HDMI2.0 and compatible with HDCP2.2 |
||
|
Resolution: |
1920x1200, 1680x1050, 1360x768, 1280x800, 1920x1080, 1600x900, 1366x768, 1280x720, 1024x576, 1920x1200, 1680x1050, 1360x768, 1280x800, 4096x2160@30Hz, 3840x2160@30Hz, 3840x2160@60Hz | ||
|
Colour space: |
1080p: 36Bit Deep Color 4K: 24Bit True Color, 4:2:0 | ||
| Data rate: | 10.2Gbps | ||
|
Transmit distance: |
CAT5e/6 cable: 220FT/70m(1080p60Hz, 110FT/35m(4K60Hz) | ||
|
Measure |
115×84×16(mm) |
||
|
Weight |
120g(do not include the package and power adapter) |
||
|
Power supply |
AC:100-240V 50/60Hz 1.5A Max DC:12V 1500mA |
||
|
Power consumption |
≤11W |
||
|
Working humidity |
0℃-50℃ | ||
|
Storage humidity |
-20℃-75℃ | ||
Transmitter Dock:
A: DC 12V input port
B: POC function OFF/ON switch
C: RJ45 output port
D: HDMI input port
E: 3-pin RS232 port
F: IR transmitter port
G: IR receiver port
H: POWER: The indicator will light up when power on
I: LINK: It will light up when the transmitter and receiver connected successfully, flecking means connection is not stable, off means the connection is failed.
J: MODE: It will flick once per second if the system runs good, on the contrary, it will be off or light up.
Receiver Dock:
A: DC 12V input port
B: POC function OFF/ON switch
C: RJ45 input port
D: HDMI output port
E: 3-pin RS232 port
F: IR transmitter port
G: IR receiver port
H: POWER: The indicator will light up when power on
I: LINK: It will light up when the transmitter and receiver connected successfully, flecking means connection is not stable, off means the connection is failed.
J: MODE: It will flick once per second if the system runs good, on the contrary, it will be off or light up.
Connection Diagram:
HDMI Source (e.g., PC, Media Player, Blu-ray Player):
Connect the HDMI output from your source device to the HDMI input on the HDBaseT Transmitter.
HDBaseT Transmitter:
Connect the HDMI input port to the source device.
Use a Cat5e/Cat6 Ethernet cable to connect the transmitter to the HDBaseT Receiver over a distance (up to 70–100 meters, depending on the model and cable quality).
Power the transmitter if required (some models may support PoE).
HDBaseT Receiver:
Connect the other end of the Ethernet cable to the receiver.
Power the receiver if it isn't powered by PoE.
Connect the HDMI output on the receiver to the HDMI input on your display device (e.g., TV, Projector, Monitor).
Display Device:
Connect the HDMI cable from the receiver to the display's HDMI input.
Hook up easy mount design of the lite version 4K30 HDBaseT Extender (Transmitter& Receiver)
The bucket mount allows for secure, stable installation, making it easy to mount on walls or other surfaces in AV setups, such as conference rooms, classrooms, or digital signage locations. The mount features perforated ventilation holes, ensuring adequate airflow to help maintain optimal operating temperatures during extended use. This design is ideal for professional installations, providing a reliable, long-term mounting solution with effective Heat sink cooling design.
Not sure which kind of HDBaseT KVM is best for your meeting room or extender on conference room or Large venue ? Contact our experts for personalized recommendations! Whether you need additional we already launch and development some new conference dock HUB with the latest USB C / HDMI / DisplayPort and USB ports, with a high-speed Ethernet, HDMI DisplayPort output, or other connectivity options, we'll help you find the perfect USB C KVM adapter to match your setup and productivity needs.
Related items KVM
If you're interested in other KVM for huddle room here are some related items that can enhance your connectivity options:
FAQ
Q: Can we get a sample?
A: yes, indeed. We offer the free sample , the delivery fee has to be paid by the customer. We will refund the sample fee after you placed an big order .
Q: I want to make the Packaging box as our design, can you do it as our requirement ?
A: Absolutely we can provide the pacakge style for optional and rendering photo in high pixels. But you should Still provide the essential informations to our graphic designer (Material, size, Printing,shape main color and so on.)
Q: what's the Minimum order quantity of yours items ?
A: For OEM, ODM, or private label products, our standard MOQ (Minimum Order Quantity) is typically 1,000 units. However, for certain items where we have stock PCBA, we can accommodate smaller orders of around 100 units. This flexibility allows us to better meet the needs of customers with varying order sizes, providing more options for customizations.
